Fix master Rivet nut, small head, closed
RIVNUT ST ROUND REDUCED CLOSED M8ZRC30B
FIX MASTER
Art.-no.
84048 30
EAN 6417926358681
Prices for customers after login
Exclusively for trade customers
Register now and access more than 20,000 products
Product information
Datasheets(X)
| 3957397.jpg"/> | |
Type description | M8 - 3 |
Material | Steel |
Product weight (per item) | 8.000 g |
Thread type | Metric thread |
Thread type x nominal diameter | M8 |
Max. grip range | 3.0 mm |
Min. grip range | 1.0 mm |
Min./max. grip range | 1.0-3.0 mm |
Shear-fracture load | 4400 N |
Design | Closed |
Nominal diameter | 8 mm |
Surface | Zinc plated |
Length | 23.0 mm |
Drill hole diameter | 11.0 mm |
Max. drill hole diameter | 11.0 mm |
Min. drill hole diameter | 11.1 mm |
Min./max. drill hole diameter | 11.1-11.0 mm |
Head diameter | 12.0 mm |
Head height | 0.6 mm |
Head type | Countersunk head |
RoHS-compliant | Yes |
Outer diameter | 10.9 mm |
Shank detail | With knurled shank |
Tensile fracture load | 25000 N |
